Bezeichnung | Wert | Einheit |
---|---|---|
Druckverhältnis | 20/1 | |
Maximaler Materialdruck | 120 (1740) | bar (psi) |
Maximaler Lufteingangsdruck | 6 (87) | bar (psi) |
Luftverbrauch | 10.8 (6.4) | m³/h (cfm) |
Maximale Temperatur | 60 (140) | °C (°F) |
Zylinder | 50 (1.69) | cc (oz) |
Schallpegel | 78 | dBa |
Empfohlener Luftdruck | 2 - 5 (29 - 72.5) | bar (psi) |
Ausbringmenge bei 30 Doppelhüben/Min | 1.5 (0.4) | l/min (gal/mn) |
Ausbringmenge bei 20 Doppelhüben/Min | 1.0 (0.26) | l/mn (gal/mn) |
Materialvolumen pro Doppelhub | 50 | cc |
Freie Ausbringmenge | 3.0 (0.78) | l/mn (gal/mn) |
Ausbringmenge bei 15 Doppelhüben | 0.75 (0.2) | l/mn (gal/mn) |
Luftverbrauch bei 30 Doppelhüben/Min bei 4 bar | 10.8 | m³/h (cfm) |
Verdrängung (pro Zyklus) | 50 (3.05) | cc (cubic inch) |
Motortyp | 500-4 | |
Lufteinlass | F3/8" BSP / F3/8" BSP | |
Materialauslass | F1/2" NPS / M1/2" JIC | |
Materialeinlass | F 1/2" BSP / M26x125 | |
Anzahl der Doppelhübe pro Liter | 20 | |
Sealing packing upper PTFE G + Polyfluid | ♦ | |
Höhe | 82 (32.2) | cm (in) |
Breite | 35 (13.8) | cm (in) |
Tiefe | 21 cm (8.3) | cm (in) |
Materialführende Teile aus Hartchrom Edelstahl, Standard Edelsta | ♦ | |
Gewicht | 17 (37.5) | kg (lbs) |
Designation | Version | Fluid inlet | Section rod | Drain rod | Paint filter | Air regulator | Seal | Part number |
---|---|---|---|---|---|---|---|---|
20C50 | Wall | M 26x125 | 25 mm (1'') | - | - | - | GT + PTFEG | 151770000 |
20C50 | Wall | M 26x125 | 25 mm (1'') | ♦ | ♦ | 2 | GT + PTFEG | 151770100 |
20C50 | Wall | M 26x125 | 25 mm (1'') | - | - | 2 | GT + PTFEG | 151770200 |
Designation | Part number | ||||
---|---|---|---|---|---|
DRAIN ROD D16 S/S CONNECTOR 18X125 | 049596000 | ||||
TROLLEY 2 ARMS | 051221000 | ||||
BRACKET W. STRAPS | 056100199 | ||||
SUCTION ROD DIAM 25 (FITTINGS 26*125) FOR EOS PUMP | 149596150 | ||||
SCUTION ROD D25 (FITTINGS 26x125) FOR 200 L DRUM | 149596160 | ||||
GRAVITY HOPPER 6L FOR EOS PUMP | 151140230 | ||||
Wall mounted support for bare pump | 044910121 | ||||
BRACKET W. STRAPS | 155580300 |
Designation | Version | Suction rod | Pump filter | Hoses lenth (m) | Gun | Gun filter | Aircap | Tip | Part number |
---|---|---|---|---|---|---|---|---|---|
20C50 + XCITE | wall | 25 mm (1'') | ♦ | 7.5 m (23 feet)) | Xcite 120 | ♦ | VX24 | - | 151260966 |
Designation | Part number | ||||
---|---|---|---|---|---|
SET OF CHEVRON SEALS FOR HYDRAULIC C50 GT | 144950091 | ||||
SERVICING KIT FOR HYDRAULIC C50 GT | 144950096 | ||||
PACKAGE OF SEALS FOR 500-4 AIR MOTOR | 146260990 | ||||
SERVICING KIT FOR MOTOR 500/4 | 146260995 | ||||
SET OF CHEVRON SEALS FOR HYDRAULIC C50 GT | 144950090 | ||||
SET OF CHEVRON SEALS FOR HYDRAULIC C50 GT | 144950095 | ||||
SET OF CHEVRON SEALS FOR HYDRAULIC C50 GT | 909051103 | ||||
Ball Ø 16, 316L stainless steel | 907414142 | ||||
Ball Ø 16, 316L stainless steel | 907414623 |
